Inspur (IEIT Systems) · Storage
NF5476M7
4U dual-socket high-density storage server (NF5476G7) with up to 60x 3.5" drives for cloud storage and archiving.
| OEM | Inspur (IEIT Systems) |
|---|---|
| Family | Storage |
| Generation | M7 |
| Released | Not published |
| Form factor | Rack 4U |
| Processor sockets | 2 |
| Processor | 4th/5th Gen Intel Xeon Scalable |
| Max cores per CPU | 64 |
| Max cores per server | 128 |
| Max CPU TDP | 385 W |
| DIMM slots | 32 |
| Memory type | DDR5, up to 5600 MT/s |
| Max memory | Not published |
| Drive bays | Up to 60x 3.5" hot-swap SAS/SATA plus up to 10x 2.5"; up to 8 NVMe + 2 M.2 |
| Max NVMe / 3.5" bays | 8 / 60 |
| GPUs | ? double-wide / ? single-wide |
| PCIe slots | 7 (PCIe Gen5) |
| OCP 3.0 slots | 2 |
| Power supplies | up to 2,000 W, redundant |
| Management | IEIT BMC (AST2600, IPMI/Redfish) |
| Suited to | Storage / file server, Backup target, Software-defined storage, Analytics / big data |
Official sources:
https://en.ieisystem.com/product/server/11424.html ↗
Spec sheet: https://en.ieisystem.com/pdf_details.thtml?id=11457 ↗
