Supermicro · Hyper
AS -1125HS-TNR
1U Hyper with 8 hot-swap 2.5" NVMe/SAS/SATA bays and 3 PCIe 5.0 x16 slots.
| OEM | Supermicro |
|---|---|
| Family | Hyper |
| Generation | H13 |
| Released | Not published |
| Form factor | Rack 1U |
| Processor sockets | 2 |
| Processor | AMD EPYC 9004/9005 |
| Max cores per CPU | 160 |
| Max cores per server | 320 |
| Max CPU TDP | 400 W |
| DIMM slots | 24 |
| Memory type | DDR5, up to 6400 MT/s |
| Max memory | 6 TB |
| Drive bays | 8 (optionally 12) hot-swap 2.5" NVMe/SAS/SATA bays + 2 M.2 |
| Max NVMe / 3.5" bays | 12 / 0 |
| GPUs | ? double-wide / ? single-wide |
| PCIe slots | 3 (PCIe Gen5) |
| OCP 3.0 slots | 1 |
| Power supplies | up to 1,200 W, redundant |
| Management | Supermicro BMC (IPMI 2.0/Redfish) |
| Suited to | Virtualisation, Database / OLTP, Hyperconverged (HCI), Containers / cloud-native, HPC |
Official sources: https://www.supermicro.com/en/products/system/hyper/1u/as-1125hs-tnr ↗
