Supermicro · Hyper
AS -2126HS-TN
2U Hyper with up to 24 hot-swap 2.5" NVMe/SAS/SATA bays and 4 PCIe 5.0 x16 slots.
| OEM | Supermicro |
|---|---|
| Family | Hyper |
| Generation | H14 |
| Released | Not published |
| Form factor | Rack 2U |
| Processor sockets | 2 |
| Processor | AMD EPYC 9005/9004 |
| Max cores per CPU | 192 |
| Max cores per server | 384 |
| Max CPU TDP | 500 W |
| DIMM slots | 24 |
| Memory type | DDR5, up to 6400 MT/s |
| Max memory | 6 TB |
| Drive bays | 8 or 24 hot-swap 2.5" NVMe/SAS/SATA bays + 2 M.2 |
| Max NVMe / 3.5" bays | 24 / 0 |
| GPUs | Up to 3 double-width GPUs |
| PCIe slots | 8 (PCIe Gen5) |
| OCP 3.0 slots | 1 |
| Power supplies | up to 2,600 W, redundant |
| Management | Supermicro BMC (IPMI 2.0/Redfish) |
| Suited to | Virtualisation, Software-defined storage, AI inference, HPC, Containers / cloud-native |
Official sources: https://www.supermicro.com/en/products/system/hyper/2u/as-2126hs-tn ↗
