Supermicro · SuperBlade
SBI-622BA-1NE12-LCC
Liquid-cooled dual-socket Xeon 6900 blade for the 6U SuperBlade enclosure, up to 100 servers per 60U rack.
| OEM | Supermicro |
|---|---|
| Family | SuperBlade |
| Generation | X14 |
| Released | Not published |
| Form factor | Blade / compute node |
| Processor sockets | 2 |
| Processor | Intel Xeon 6 (6900 series) / Xeon 6+ |
| Max cores per CPU | Not published |
| Max cores per server | Not published |
| Max CPU TDP | 500 W |
| DIMM slots | 24 |
| Memory type | DDR5 (RDIMM/MRDIMM), up to 8800 MT/s |
| Max memory | 6 TB |
| Drive bays | 2 hot-swap E1.S NVMe bays (+ optional 2 M.2) |
| Max NVMe / 3.5" bays | 2 / 0 |
| GPUs | Up to 2 low-profile single-width PCIe 5.0 x16 GPUs |
| PCIe slots | 2 (PCIe Gen5) |
| OCP 3.0 slots | 1 |
| Power supplies | ? |
| Management | Supermicro BMC + SuperBlade CMM (IPMI 2.0/Redfish) |
| Suited to | HPC, AI inference, Containers / cloud-native |
Official sources: https://www.supermicro.com/en/products/superblade/module/sbi-622ba-1ne12-lcc.php ↗
