Supermicro · GPU
SYS-A22GA-NBRT
10U air-cooled system with dual Intel Xeon 6900 and NVIDIA HGX B200 8-GPU.
| OEM | Supermicro |
|---|---|
| Family | GPU |
| Generation | X14 |
| Released | Not published |
| Form factor | Rack 10U |
| Processor sockets | 2 |
| Processor | Intel Xeon 6 (6900 series P-core) |
| Max cores per CPU | 128 |
| Max cores per server | 256 |
| Max CPU TDP | 500 W |
| DIMM slots | 24 |
| Memory type | DDR5 (RDIMM/MRDIMM), up to 8800 MT/s |
| Max memory | 6 TB |
| Drive bays | 10 front hot-swap 2.5" PCIe 5.0 NVMe bays + 2 M.2 |
| Max NVMe / 3.5" bays | 10 / 0 |
| GPUs | NVIDIA HGX B200 8-GPU (SXM, 180GB HBM3e each) with NVLink/NVSwitch |
| PCIe slots | 12 (PCIe Gen5) |
| OCP 3.0 slots | Not published |
| Power supplies | up to 5,250 W, redundant |
| Management | Supermicro BMC (IPMI 2.0/Redfish) |
| Suited to | AI training, AI inference, HPC |
Official sources: https://www.supermicro.com/en/products/system/gpu/10u/sys-a22ga-nbrt ↗
